Super Thin Curved Outdoor Rental LED Display P5.95 5000nits Brightness 500*1000mm Size

Shenzhen Haojingyuan Optoelectronic Co.,Ltd
Contact Now

Super Thin Curved Outdoor Rental LED Display P5.95 5000nits Brightness 500*1000mm Size

  • 1
  • 2

Brand Name : HJY

Model Number : P5.95

Certification : CE FCC

Place of Origin : China

MOQ : negotiable

Price : negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000sqm per month

Delivery Time : 15-20 days after receiving deposit

Packaging Details : Flight case

Pixels : 5.95mm

Driving Method : 1/7scan

Brightness : 5000nits

IP rating : IP65

Life span : 100,000hours

Warranty : 2 years

Contact Now



outdoor rental led display super thin curve led display P5.95 500*1000mm



led wall





P5.95 outdoor rental led display
Module Pitch/mm P5.95
  Module size/mm 250x250
  Density of pixel/(dots/m2) 28,224
  Pixel composition 1R1G1B
  Led encapsulation SMD3535
  Resolution of module 42x42
  Optimum viewing distance ≥6-50m
Main View angle / ° 160 H,140 V
  Average power consumption/W/M2 260
  Max power consumption/W/M2 520
  Size of cabinet/mm 500x1000x80mm
  Resolution of cabinet 84*168/84*84
  Weight of cabinet/kg 13
  Driving method 1/7 scan constant current
  Frame frequency / Hz/S 60
  Refresh rate Hz/S ≥1920hz
  Luminance of white balance 5000 nits
  Operation of Environmental Temperature/ below 30 to above 50
  IP rating IP65
  Working vlotage 110-220 VAC/+/- 10%
  Grey scale/color displaying colors16.7M(synchronized)
  Brightness adjustment 256 levels of each color(manually),100 levels of each color(automatically)
  Input signal RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
  Control system Nova (sending card,receiving cards and Hubs)
  Average of non-failure life >50,00h
  Life span >100,000h
  Functionless dot rate <0.0001


Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.

After-sale service:
1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Free technician training.
3. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
4. Special service for big project, such as stadium, exhibitions, squares and so on.



Super Thin Curved Outdoor Rental LED Display P5.95 5000nits Brightness 500*1000mm SizeSuper Thin Curved Outdoor Rental LED Display P5.95 5000nits Brightness 500*1000mm Size
